technical specifications Port connection: NG10 / CETOP 05 Operation type: Pilot Startup type: Proportional, Solenoid Current Speed: 75 L/Min Function: 3-way Maximum flow rate: n/a Valve core position: Operated in position a or b Pilot inlet/drainage location: External / internal Maximum operating pressure: 350 bar Sealing material: FPM Maximum operating temperature: 60 ° C Signal input: 4 - 20 mA Minimum operating temperature: -20 ° C Flow direction: 12 - 20 mA = P-A Used in conjunction with fluid types: Hydraulic Oil According to DIN 51524 ... 535, Water-Glycol According to DIN 51524 ... 535 Weight: 9.3 kg Product sequence: Proportional DC Valve Installation type: Subplate Sealing material: FPM Valve body material: Cast Iron Maximum ambient temperature: 60 ° C Minimum ambient temperature: -20 ° C Filter efficiency rating: ISO 4406; 18/16/13 Leakage rate: 100.0 ml/min Installation method: DIN 24340 / ISO 4401 / CETOP RP121 / NFPA Application: Industrial Hydraulic Brand: Parker Technology: Hydraulics branch: Industrial Systems Division Europe Valve type: Proportional DC Valve Medium: Hydraulic Oil Maximum fluid temperature: 60 ° C Minimum fluid temperature: -20.0 ° C Electronic type: Onboard Current Speed: 75.0 L/min Maximum kinematic viscosity: 400 cSt Minimum kinematic viscosity: 20 cSt Vibration resistance: 10 Sinus 5...2000 Hz acc. IEC 68-2-6 10 (RMS) Random noise 20...2000 Hz acc. IEC 68-2-36 15 Shock acc. IEC 68-2-27 g Installation position: Unrestricted Change in opening point: set to 10 % command signal Response time: 50.0 ms Protection level: IP65 in accordance with EN 60529 Valve options: Standard Power supply voltage: 18...30, ripple < 5 % eff., surge free Vaximum pilot pressure: 350 bar Minimum pilot pressure: 30 + T/Y bar Lag: < 5 % Connection type: 6 + PE Valve core code: B32
aximum pilot pressure: 350 bar
